The map contains the 65.1km 8″ Afyon – Emirdağ Natural Gas Pipeline, which receives gas from Konya – Izmir Natural Gas Transmission Line in Çay, Afyon, and supplies the gas to Emirdağ, Afyon.
Table of Descriptions
1 Product Details
2 Files Included in This Digital Map
展开剩余81%3 Editability of Map
4 Related Upstream/Downstream Pipelines
1 Product Details
Product Name: Map of Afyon – Emirdağ Natural Gas Pipeline Ürün Adı: Afyon – Emirdağ Doğal Gaz Boru Hattı Haritası Product Type: Vector Map Pipeline Length: 65.1km Country: Türkiye (Turkey) From: Çay, Afyon To: Emirdağ, Afyon No. of Pigging Stations: 2 No. of Line Valve Stations: 2 Coordinate Data: Not Available File Formats: Adobe PDF, Adobe Illustrator Lifetime Updates: Supported Language: EnglishNote: This digital map is NOT a GIS map or don’t contain coordinate data.
2 Files Included in This Digital Map
[Main Map] Afyon – Emirdağ Natural Gas Pipeline
This map includes the geographical area from the pipeline’s starting point to its end point. Its content contains the pipeline route, stations along the pipeline, and the administrative regions that the pipeline passes through.
Two file formats, .pdf and .ai (Adobe Illustrator), are included. Both of them are editable and layered. Users can show and hide a layer simply with a mouse click.
The map consists of following independent layers:
Project Name and Legend Names of Main Stations Names of Line Valve Stations Names of Provinces Names of Districts Main Stations Line Valve Stations Pipeline Water Borders of Provinces Borders of Districts Background Color3 Editability of Map:
Based on the layered digital map (.pdf and .ai), users can perform further development and modifications, including but not limited to:
Adjusting the position of text and modifying its attributes such as font, font size, and color; Adjusting the position and size of icon symbols; Modifying the path of oil and gas pipelines to reflect changes caused by rerouting; Adding new pipelines and stations; Changing the border color and line weight of different administrative regions; Modifying the map background color.4 Related Upstream/Downstream Pipelines:
We also provide digital maps of following direct upstream/downstream pipelines.
Upstream Pipelines:
Konya – Izmir Natural Gas Transmission Line
